TECHNICAL SPECIFICATIONS
Specification UT1500E UT2200E
Model Name UT1500E UT2200E
UPS Topology Line-Interactive Line-Interactive
Energy Saving Technology
INPUT
Parameter UT1500E UT2200E
Generator Compatibility Yes Yes
Nominal Input Voltage 230 ± 10% Vac 230 ± 10% Vac
Input Voltage Range 167 – 295 Vac 167 – 295 Vac
Input Frequency 50 / 60 Hz 50 / 60 Hz
Input Frequency Detection Auto-sensing Auto-sensing
Rated Input Current 6.52 A 10 A
Input Connector Type
OUTPUT
Parameter UT1500E UT2200E
Capacity (VA) 1500 VA 2200 VA
Capacity (Watts) 900 W 1320 W
On Battery Waveform Simulated Sine Wave Simulated Sine Wave
On Battery Voltage 230 ± 10% Vac 230 ± 10% Vac
On Battery Frequency 50 ± 1%, 60 ± 1% 50 ± 1%, 60 ± 1%
Automatic Voltage Regulation Single Boost, Single Buck Single Boost, Single Buck
Overload Protection Internal Current Limiting, Circuit Breaker Internal Current Limiting, Circuit Breaker
Total Outlets 4 4
Outlet Type IN / ZA × 4 IN / ZA × 4
Battery & Surge Protected Outlets 4 4
Typical Transfer Time
BATTERY
Parameter UT1500E UT2200ERuntime at 60W 90 min 95 min
Runtime at 90W 60 min 70 min
Runtime at 200W 27 min 34 min
Typical Recharge Time 8 Hours 8 Hours
User Replaceable No No
Battery Type
SURGE PROTECTION & FILTERING
Parameter UT1500E UT2200E
Surge Suppression 150 Joules 150 Joules
EMI / RFI Filtration Yes Yes
Phone / Network Protection 1-in, 1-out 1-in, 1-out
Sealed Lead-acid
Sealed Lead-acid
4 ms 4 ms
IN / Z
IN / ZA
